The study, undertaken as part of the GW3D project (2015-2019), comprised three parts:

1) Desk study and fieldwork preparation.

​

Sand and gravel bodies above a minimum size criterion were extracted from the GSI Quaternary Sediments 1:50,000 map. Where it was known that the surface expression of the sands and gravels was only a small portion of the subsurface body, such areas were retained. This process left several hundred sand and gravel bodies remaining as a starting point for field work.

2) Fieldwork including mapping and data collection.

Field work included a visit to each of the areas which had the potential to be (at least) a Locally Important Sand and Gravel Aquifer owing to its area. In such areas, gravel pits and sand pits were visited and depth and type of sediment recorded, other exposures into the subsurface were visited and logged, wells (whether Public Supply, Group Scheme or private farm or domestic) were dipped and any information on depths recorded, and data was collected where geological and hydrogeological data existed for the area.

3) Data collation, analysis and reporting.

All field data, and information from earlier reports and studies, were compiled and analysed. Where a sand and gravel body had qualifying aquifer properties (either 10 m depth sand and gravel, or 5 m depth saturated sediments), these areas were digitised in a GIS. The aquifer area was then ascertained and drawn up. Such areas formed the basic building blocks for the sand and gravel aquifer map, which included details on the aquifer name, area, aquifer resource value, confidence level, county, and any important aspects to note for each body.

The updated mapped sand and gravel aquifers are found on the Geological Survey Ireland site.
